| JUHONG PACKING MATERIALS | Terra | Ridge | Pivot | Duro | Nexa | ![]() | |||||||||||||||
| Width | Thickness | Average Strength | Average Strength | Average Strength | Average Strength | Average Strength | Length/Weight | Coil | |||||||||||||
| in | mm | in | mm | lbs | N | N/mm² | lbs | N | N/mm² | lbs | N | N/mm² | lbs | N | N/mm² | lbs | N | N/mm² | ft/lb | m/kg | Winding |
| 1/2 | 12.7 | 0.015 | 0.38 | 706 | 3137 | 650 | / | / | / | / | / | / | / | / | / | / | / | / | 39.2 | 26.5 | M/R |
| 1/2 | 12.7 | 0.020 | 0.51 | 947 | 4210 | 650 | 1093 | 4858 | 750 | 1209 | 5376 | 830 | 1282 | 5700 | 880 | 1428 | 6347 | 980 | 29.4 | 19.8 | M/R/O/J |
| 1/2 | 12.7 | 0.023 | 0.58 | 1077 | 4788 | 650 | 1243 | 5525 | 750 | 1375 | 6114 | 830 | 1458 | 6482 | 880 | 1624 | 7219 | 980 | 25.6 | 17.2 | M/R/O/J |
| 5/8 | 16 | 0.015 | 0.38 | 889 | 3952 | 650 | / | / | / | / | / | / | / | / | / | / | / | / | 29.6 | 20.0 | M/R |
| 5/8 | 16 | 0.020 | 0.51 | 1193 | 5304 | 650 | 1377 | 6120 | 750 | 1524 | 6773 | 830 | 1615 | 7181 | 880 | 1799 | 7997 | 980 | 23.6 | 15.9 | M/R/O/J |
| 5/8 | 16 | 0.023 | 0.58 | 1357 | 6032 | 650 | 1566 | 6960 | 750 | 1733 | 7702 | 830 | 1837 | 8166 | 880 | 2046 | 9094 | 980 | 20.5 | 13.8 | M/R/O/J |
| 3/4 | 19 | 0.020 | 0.51 | 1417 | 6299 | 650 | 1635 | 7268 | 750 | 1809 | 8043 | 830 | 1918 | 8527 | 880 | 2136 | 9496 | 980 | 19.6 | 13.2 | M/R/O/J |
| 3/4 | 19 | 0.023 | 0.58 | 1611 | 7163 | 650 | 1859 | 8265 | 750 | 2058 | 9147 | 830 | 2182 | 9698 | 880 | 2429 | 10800 | 980 | 17.1 | 11.5 | M/R/O/J |
| 3/4 | 19 | 0.028 | 0.71 | 1973 | 8769 | 650 | 2276 | 10118 | 750 | 2519 | 11197 | 830 | 2671 | 11871 | 880 | 2974 | 13220 | 980 | 14.2 | 9.6 | M/R/O/J |
| 3/4 | 19 | 0.031 | 0.79 | 2195 | 9757 | 650 | 2532 | 11258 | 750 | 2803 | 12458 | 830 | 2971 | 13209 | 880 | 3309 | 14710 | 980 | 12.5 | 8.4 | M/R/O/J |
| 3/4 | 19 | 0.035 | 0.89 | 2473 | 10992 | 650 | 2853 | 12683 | 750 | 3157 | 14035 | 830 | 3348 | 14881 | 880 | 3728 | 16572 | 980 | 11.1 | 7.5 | M/R/O/J |
| 1 | 25 | 0.031 | 0.79 | 2888 | 12838 | 650 | 3332 | 14813 | 750 | 3688 | 16393 | 830 | 3910 | 17380 | 880 | 4354 | 19355 | 980 | 9.5 | 6.4 | M/R/J |
| 1 | 25 | 0.035 | 0.89 | 3253 | 14463 | 650 | 3754 | 16688 | 750 | 4154 | 18468 | 830 | 4405 | 19580 | 880 | 4905 | 21805 | 980 | 8.5 | 5.7 | M/R/J |
| 1 1/4 | 31.75 | 0.028 | 0.71 | 3296 | 14653 | 650 | 3803 | 16907 | 750 | 4209 | 18710 | 830 | 4463 | 19837 | 880 | 4970 | 22092 | 980 | 8.5 | 5.7 | M/R/J |
| 1 1/4 | 31.75 | 0.031 | 0.79 | 3668 | 16304 | 650 | 4232 | 18812 | 750 | 4683 | 20818 | 830 | 4965 | 22073 | 880 | 5530 | 24581 | 980 | 7.4 | 5.0 | M/R/J |
| 1 1/4 | 31.75 | 0.035 | 0.89 | 4132 | 18367 | 650 | 4768 | 21193 | 750 | 5276 | 23454 | 830 | 5594 | 24867 | 880 | 6230 | 27692 | 980 | 6.7 | 4.5 | M/R/J |
| UltiMax HT | ||||||||||||
| Width | Thickness | Average Strength | Elongation | Length/Weight | Coil | AAR OTLR Status | ||||||
| in | mm | in | mm | lbs | N | N/mm² | % (L=100mm ) | ft/lb | m/kg | Winding | ||
| 3/4 | 19 | 0.031 | 0.79 | 3444 | 15310 | 1020 | ≥10% | 12.5 | 8.4 | R/O/J | Verified (AAR:ID 124) | |
| 1 1/4 | 31.75 | 0.031 | 0.79 | 5755 | 25584 | 1020 | ≥10% | 7.4 | 5 | R/O/J | Verified (AAR:ID 124) | |
A:Buyers should choose a steel strapping manufacturer or supplier by checking available width, thickness, strength grade, surface finish, coil type, packaging method, and matching seals or tools. For industrial packaging, the supplier should understand the load type, transport method, edge condition, and required tension instead of only offering a general product list.JUHONG is a steel strapping manufacturer with manufacturing experience since 1997 and can support buyers with specification selection for heavy-duty industrial packaging.
A:In industrial packaging, steel strapping and steel banding are often used to describe the same type of steel packaging strap. Metal strapping is a broader term and may refer to steel strapping or other metal banding materials depending on the context.For purchasing, buyers should confirm the material, width, thickness, strength grade, surface finish, coil type, and compatible seals or tools.
A:Many steel strapping applications require matching seals, tensioners, sealers, cutters, or strapping machines. The correct combination depends on strap width, thickness, joint method, packaging volume, and working environment.Buyers should confirm steel strapping, seals, and tools together to avoid weak joints, poor tensioning, tool mismatch, or unstable packaging during transport.
